Rear Projection (DLP)

Flat Panel LCD

Flat Panel Plasma

Key terms:

An integrated HDTVhas a built-in digital ATSC tuner and has resolution of 720p or higher. Since 2007, the majority of new televisions sold have been HDTVs. That is because beginning March 1, 2007, all television reception devices imported into the U.S. or shipped via interstate commerce must contain a digital tuner. Thus, all new TVs sold by retailers should be equipped with a digital tuner. Nearly all also have HD quality resolution, deeming most new TVs to be HDTVs. To receive and display any free and available over-the-air HD broadcasts on your HDTV, all you need to do is purchase an HD antenna. Or you can simply plug into your existing digital cable or satellite set-top box; however, some carriers may charge extra for an HD-compatible set-top box or require you to subscribe to additional programming to receive HD broadcasts.

Contrast Ratio -  This refers to the difference between the brightest whites and the darkest blacks a TV can display.  The key thing to consider is how “black” your blacks will be. A higher contrast ratio means a deeper black. In addition, a higher contrast ratio also means you can have more ambient light in the room without washing out the on-screen color. As of 2006, contrast ratios range from 300:1 to 5000:1 for home theatre projectors to 10,000:1 on high-end plasma and LCD TVs.

Frame rate – A TV’s frame rate describes how many times it makes a complete picture on the screen every second. Again, the higher the number, the faster images are processed. This makes a difference when watching fast-moving action or playing fast-paced video games with lots of action. The two most common numbers you’ll see are 720p and 1080i.

What do the “I” and “p” mean? The “I” indicates that the TV draws images using an interlaced method. The “p” indicates that the TV draws images using a progressive scan method. In general, progressive scan renders images faster and produces a more detailed, film-like image.

HDMI – High-Definition Multimedia Interface, or HDMI, is a new type of connector cable that carries both all-digital audio and video signals over a single cable, eliminating the need for separate cables to connect your audio and video components. No more tangled mess of cables! In addition, HDMI cables deliver the best possible digital quality signals for both audio and video.

Response Time -  This refers to the time it takes a pixel to change state from black-to-white-to-black again. In general, the faster the response time, the better the picture, especially when viewing fast action in movies, sports, and video games. Plasma and CRT televisions have virtually instantaneous response time, while LCD models tend to be a bit slower. The slower response time can result in what is referred to as “image lag” or a slight blurring of fast-moving images. As of 2007, a “fast” response time is considered to be anywhere from 8msec to 3msec.
